Laser ống sợi quang - tự động - 6 m

DURMA HD-TC 60170

ONLY approx. 8,700 hours of operation - available immediately

Used fiber tube laser cutting machine with automatic feed and discharge

Manufacturer: DURMA
Model: TC HD-60170
Year of manufacture: 2017 (commissioned in June 2019)
Control: Siemens Sinumerik 840 D SL
Operating hours: ONLY approx. 8,700 hours
Possible cutting variants of the profile: round, square, rectangular

TECHNICAL DATA:
Max. tube diameter: 170 mm
Max. profile dimensions in a square: 120 x 120 mm
Max. profile dimensions in a rectangle: 150 x 100 mm
Min. tube diameter: 20 mm
Max. material length: 6,500 mm
Min. material length for automatic loading: 3,000 mm
Material length of the last cut: 185 mm
Unloading length: 6,000 mm
Max. material weight: 37.5 kg/m
Max. total workpiece weight: 210 kg
Max. bundle weight: 3,000 kg
X axis: 90 m/min.
Y axis: 50 m/min.
Z axis: 45 m/min.
A axis: 1200 °/s.
Max. cutting thickness:
- Structural steel: 8 mm
- Stainless steel: 4 mm
- Aluminum: 6 mm
- Copper: 2 mm
- Brass: 4 mm

Laser power: 2,000 watts
Laser source: IPG Fiber

Space requirement: 16,000 x 7,400 mm
Machine weight: 20,000 kg

EQUIPMENT:
- Precitec cutting head (Light Cutter)
- Vanterm compact filter system
Cjdjvylnzjpfx Agnohc
- Automatic weld seam detection
- Automatic real-time measuring system for centering chucks

AUTOMATION:
- Automatic loading system (6,500 mm)
- Unloading unit (6,000 mm)
- Conveyor belt for unloading including small parts conveyor to the rear

SAFETY:
- Light barriers

Detailed information and the machine layout can be found under Documents for download.

Subject to prior sale. Sale excluding any guarantees and within the framework of our general terms and conditions. All statements without guarantee.
