Máy cắt laser

TRUMPF TruLaser 3030 (L20) 5000 Watt

CNC Laser Cutting System TruLaser 3030 (L20) 5000 Watt

Maximum Working Area:
X-axis: 3000 mm
Y-axis: 1500 mm
Z-axis: 115 mm

Control: Siemens Sinumerik 840D SL
Laser Power: 5000 Watts
Operating Hours: 59,167 hrs
Laser On Time: 19,307 hrs

Sheet Thickness
Steel, max.: 25 mm
Stainless steel, max.: 20 mm
Aluminium, max.: 12 mm

Standard Equipment

Machine
- Enclosed machine frame with integrated laser unit
- Motion unit for high-precision processing
- Automatic longitudinal pallet changer
- Longitudinal conveyor belt
- Torque drive combined with linear direct drives
- Enclosed beam guidance
- NitroLine
- FocusLine
- PlasmaLine
- SprintLine
- Spraying device
- Positioning laser diode
- Programmable cutting gas pressure
- Single-cutting head strategy
- Workspace lighting
- PierceLine

TRUMPF Laser
- CO2 laser TruFlow 3200 with optimized standby mode
- Maintenance-free turbo radial blower
- High-frequency excitation
- Beam telescope
- Laser control TASC
- Laser power control
- Laser logbook function
- Cooling unit

Cutting Head
- Lens cutting head with 250mm focal length
- Universal quick-change cutting head system (UTI)
- ControlLine: Height regulation and edge detection

Control
Chedpfsxb Trajx Agnoc
- 17" touch color screen
- User-friendly operation
- Online help
- Integrated e-shop
- Diagnostic functions
- Integrated technology data
- Auto shut-off
- Teleservice
- ContourLine
- Microweld
- FastLine

Data Transmission
- USB interface
- RJ-45 network connection

Safety
- CE marking
- Light barriers
- Monitoring system
- Multi-chamber extraction system
- Compact dust extraction unit
- Machine enclosure with Makrolon panels

+ TruFlow 5000
