Trung tâm tiện và phay CNC

Mori Seiki SL 2500 Y

* Mori Seiki SL 2500 Y
* 4-axis machine
* Sandvik Capto quick-change system valued at €22,000
* Hydraulic, programmable tailstock
* 12-station turret, all stations driven
* Y-axis travel: ±60 mm
* C-axis
* Main spindle integrated motor, 18.5 kW
* Driven tool motor: 5.5 kW
* Starting torque 640 Nm
* Integrated, beltless main spindle motor
* Main spindle nose size: A2-8
Nwedsxrlirepfx Adlsn
* Tailstock: Morse taper MT5
* Bar capacity: 75 mm
* Main spindle chuck: Kitagawa B-210, 250 mm, metric system
* Box ways on all axes
* Main spindle speed: 3,500 rpm
* Driven tool speed: 4,000 rpm
* Swing diameter: 755 mm
* Max. turning diameter: 390 mm
* Max. turning length: 655 mm
* Spindle head oil cooler: Daikin
* Automatic conversational programming system: Mapps 4
* Tool load monitoring and consumption monitor
* Rapid traverse speeds: 18 and 24 m/min on X and Z axes
* Turret index time: 0.2 seconds
* Renishaw automatic tool measurement arm
* Communication ports: USB, PCMCIA card, and RS-232
* Bar feeder interface
* Automatic parts catcher
* Dual pedal for chuck and tailstock open/close
* Side-mounted chip conveyor, hinged type
* Comprehensive range of static and driven toolholders included
* Electrical transformer
* Documentation: parts lists, electrical diagrams, programming, and operator’s manual
* Weight: 5,800 kg
* Machine currently in operation
* Immediate delivery unless sold
