Stadler Keppler Maschinenbau GmbH HDC 3000, 5-achsig

• Traveling distances X=3100 mm, Y=1950 mm, Z=1390 mm
• Heidenhain iTNC 530 with handwheel HR 410
• Machine table for multi side working 3000 mm x 1600 mm
• 2-axis NC-universal milling head, for simultaneous and positioning
working
• Spindel 10.000 U/min HSK 100, 130 Nm Spindle torque
• Tool change system HSK 100 / 40 places for 750 mm long tools
• Chip conveyor (screw type) in X-axis, for transport into
• Chip conveyor scraper belt type (traverse conveyor), Fabr. Knoll
• Coolant container 900 l, Fabr. Knoll
• Outside air at spindle
• IKZ 60 bar for deep hole drilling function
• Covering with safety glass pane, open at the top for loading by
crane
• 2 part sliding doors at the operator side
• 2 part sliding doors at the front side, for easy loading
• Radio-controlled measuring probe RMP 60
• incl. washing gun
• incl. podiums at the front side and operator side
• complete factory overhauled and painted new
• short time delivery after arrangement
• used machine
• Y-axis ball screw in September 2021 incl. bearings renewed
Chedpfx Asxbpukognsc
• X-axis new linear guiding system, July 2023 changed, renewed
• Spindle overhauled at Mai 2023 (clamping system new, clamping
cartridge new, rotation unit new, general tests) (at 23105 spindle
hours))
• can be visited under power at 72793 Pfullingen
• optional fixators
• optional installation at customers plant
• optional transport
• 23122 spindle hours in total
• 53991 machine hours in total
• Year of construction 2010
Subject to prior sale
