Máy chà nhám đai rộng đôi

Qindao Haohailong Woodworking Machinery BSG2613C

Double-sided grinder
Production date: 07.2019
New not used.

1) Net weight: 15000 kg
2) Dimensions: 2200 x 3100 x 3050 mm
3) Higher grinding speed
4) High precision

Technical specifications
1) Grinding width (max): 1300 mm
Nedpfx Ast Dmmcod Eoli
2) Grinding thickness: 5-150 mm
3) Grinding length:> 700 mm
4) Abrasive belt speed: 25 m/s
5) Abrasive belt dimension: 1350 x 2800 mm

6) Total motor power: 163.25 kW
7) Grinding head motor: 75 kW x 2
8) Motor for feeding: 11KW
9) Lift motor: 0.75 kW
10) Brush motor: 0.75 kW x 2

11) Feeding speed: 10-30 M/min
12) Power supply: 380 V 50 Hz
13) Working pressure: 0.6-0.8 MPa
14) Extraction capacity: 24000m³/h
a. Thickness of sanding boards in large range: 5-150mm.
b. Machining plate thicknesses greater than 25mm with good quality.
c. The upper and lower conveyor pressure roller adopts double power transmission, so that the transmission efficiency is increased and smooth operation is maintained. It can ensure grinding with high accuracy and good surface quality.
d. To meet the needs of different plate processing, they used variable frequency and adjustable speed system and variable speed motor for conveying.
e. Siemens electrical parts were selected as the main parts with long service life.
