DÂY CHUYỀN SẢN XUẤT TẤM PIN NĂNG LƯỢNG MẶT TRỜI (PV)

ARGUS SUNIC 2023

We offer this as new SOLAR PHOTOVOLTAIC (PV) PANEL/MODULE PRODUCTION LINE, year of construction 2023.

A solar panel manufacturing facility for sale capable of processing both PERC and TOPCon solar cells and producing a wide range of popular PV modules currently demanded in the market. The fully automated production line has an annual capacity of 250 MW and can manufacture various module configurations, including 450W, 585W, and 630W class modules with TOPCon 16BB technology, available in black frame with black backsheet, glass-to-glass, white backsheet, and transparent backsheet options. The facility is also capable of producing 10BB PERC modules up to 550W. Equipped with a double-layer double-chamber laminator, automatic framing system, automatic sorting system, and fully integrated high-efficiency manufacturing processes, this turnkey production line offers flexible production capabilities for today’s leading solar panel designs. With a highly competitive price, this is a rare investment opportunity for serious buyers seeking to enter or expand in the solar PV manufacturing industry.

Popular panel types like 550 W PERC , 585 W TOPCON Glass to Glass ; 630 W TOPCON Glass to Glass can be produced with this line.

Manufacturer: ARGUS SUNIC
Model: 2023
Year of manufacture: 2023
Condition: as new
Category ID: 33
Machine type: SOLAR (PV) PANEL PRODUCTION LINE

Production capability: Complete photovoltaic (PV) module manufacturing line covering the entire production process from cell stringing to final testing and sorting

Supported solar cell types:
182 × 182 mm 10BB PERC (M10);
210 × 210 mm 12BB PERC (M12);
182 × 182 mm 16BB TOPCon (M10);
182 × 210 mm 16BB TOPCon (G12R)


Layout: Existing layout is shown in the photos

Includes Tabber & Stringer
Includes Automatic Robot Layup System
Includes Automatic Glass Feeding & Transfer System
Includes EVA Cutting & Layup Machines
Includes TPT/Backsheet Cutting & Layup Machine
Includes Automatic Bussing Station
Includes Automatic Taping Station
Includes Automatic Double Glass Feeding & Die Spotting Machine
Includes Automatic Double-Chamber Laminator
Includes Automatic Frame Gluing & Framing Machine (3-in-1)
Includes Automatic Edge Banding Machine
Includes Automatic Edge Trimming Machine
Includes Junction Box Glue Filling Machine
Dodpfx Aoznmhhslcekt
Includes Junction Box Gluing Machine
Includes EL Inspection System
Includes IV Module Tester (A+A+A+ Class)
Includes Hi-Pot Tester
Includes Automatic Module Sorting Machine
Includes Automatic Laser Scribing Machine
Includes Solar Cell Tester
Includes Automatic Corner Grinding Machine
Includes Automatic Corner Wrapping Machine
Includes Automatic Module Loading & Unloading System
Includes Plate Chain Curing Conveyor
Includes Glass Stacking Machine
Includes Visual Inspection Stations
Includes Flip Inspection Table
Includes Conveyor Systems (Transverse & Longitudinal)
Includes Buffer Stations
Includes Rotary Units
Includes Corner Turning Units
Includes Barcode Printing System
Includes Control Cabinets
Includes Material Handling Trolleys & Auxiliary Equipment

If you have any questions or need more information, feel free to send us a message or give us a call.
