Constmach Dewatering screen sand washing Dewatering screen sand washing equipment

For Sale: Dewatering Screens and Hydrocyclones - Contact Us 24/7

CONSTMACH dewatering screens offer ideal solutions for washing fine materials, delivering excellent performance, especially for materials up to 7 mm in size. A key advantage of these products in fine material washing applications is their ability to retain particles as small as 50 microns. In traditional washing systems, it's challenging to retain micronized material within the sand, which is where CONSTMACH Dewatering Screens and Hydrocyclones provide significant innovation.

The use of CONSTMACH dewatering screens and hydrocyclones ensures the conservation of micronized material and water, reducing costs with low power and water consumption. Thanks to their durable PU screen material, these systems require minimal maintenance over time. Additionally, they offer easy maintenance and produce dry, easily storable final materials. These features help users produce according to the varying needs of different projects.

These systems, which can also be used as sand washing machines, are available in various models to suit all capacities. The CDS-1225 model, with a production capacity of 60-80 tons/hour, is ideal for small and medium-sized projects. The CDS-1635 model, with a capacity of 100-150 tons/hour, caters to larger projects, while the CDS-2040 model, with a capacity of 150-200 tons/hour, offers the highest efficiency.

By choosing CONSTMACH Dewatering Screens and Hydrocyclones, you can achieve both cost advantages and high-quality production in your projects. With their high performance and durability, CONSTMACH products meet all your needs.

CDS-1225 Dewatering Screen Technical Specifications:

Dewatering Screen Dimensions: 1,200 x 2,500 mm
Hydrocyclone Diameter: 20”
Slurry Pump Motor Power: 37 kW
Vibrator Motor Power: 2 x 4.5 kW
Production Capacity: 60 - 80 tons/hour
CDS-1635 Dewatering Screen Technical Specifications:

Dewatering Screen Dimensions: 1,600 x 3,500 mm
Hydrocyclone Diameter: 26”
Cedpsud Stasfx Agnjhc
Slurry Pump Motor Power: 55 kW
Vibrator Motor Power: 2 x 7.5 kW
Production Capacity: 100 - 150 tons/hour
CDS-2040 Dewatering Screen Technical Specifications:

Dewatering Screen Dimensions: 2,000 x 4,000 mm
Hydrocyclone Diameter: 2 x 26”
Slurry Pump Motor Power: 75 kW
Vibrator Motor Power: 2 x 11 kW
Production Capacity: 150 - 200 tons/hour
