Máy ly tâm tách bùn clarifier decanter 2019

GEA Westfalia OCE 305-01-32

Complete Technical Data (GEA OCE 305-01-32)
Technical ParameterSpecification and Values
Manufacturer & ModelGEA Westfalia Separator Group GmbH – OCE 305 Series
Equipment TypeHigh-performance 2-phase decanter centrifuge (Solid-Liquid)
Bowl Inner Diameter305 mm
Bowl DesignFlat-cone design with an extended length (Extended L/D ratio)
Maximum Hydraulic CapacityUp to 5 m³/h (varies depending on solid concentration)
Maximum Solids Density2.6 kg/dm³
Drive Type2-Gear Drive (System with 2 independent motors, no magnetic brake)
Differential Speed ControlAutomatic via dedicated Variable Frequency Drives (VFD)
Overall DimensionsLength: 3000 mm | Width: 1000 mm | Height: 1150 mm
Total Weight (Complete Skid)Approx. 2500 kg
Lubrication SystemAutomatic centralized grease lubrication for main bearings
Construction MaterialsHigh-grade duplex stainless steel (all product-contact areas)
Scroll Wear ProtectionSintered tungsten carbide tiles welded onto the flight edges

II. Liquid Discharge Under Pressure System
Rjdpfxszgq Szo Ad Sjw
Unlike standard models with gravity discharge (where the liquid falls freely into a collection tank), your model retains the clarified liquid phase inside a hydro-hermetic tripetal Pump (Paring Disk): The separated liquid flows toward the cylindrical end of the bowl, entering a special chamber where a stationary disk with spiral internal channels (a reverse turbine) is located.
Kinetic-to-Pressure Energy Conversion: The kinetic energy of the rapidly rotating liquid is instantly transformed into hydrostatic pressure when it hits the channels of the stationary disk.
Advantages: The liquid leaves the decanter directly under pressure (without requiring an external transfer pump). This prevents product foaming (highly critical for oils, chemical products, or food-grade applications) and eliminates contact with atmospheric oxygen.
Electrical cabinet with frequency inverters and PLC (Siemens) with an access code for modifying the parameters, including factory documentation.
